LCP Black Gold Plated 3 Pin Double Layer Pin Header SQ1.14 Connector L16.8
Product features: Environmental protection and high temperature resistance plastic, high conductivity of brass conductor, durable, stable tin or gold plating performance, oxidation resistance and external factors interference, long service life.
Product function: It is made of brass wire, phosphorus copper wire, copper clad steel wire, pure copper wire, tin plating nickel surface after the bottom, bottom plated nickel.
Application scope: It is widely used in display, digital camera, MP3, MP4, PDA, computer, computer motherboards, mobile storage disk, card reader, security products, electricity meter, wireless telephone, mobile phone, interphone, program-controlled switches, VCD, DVD, LCM/LED display module, electronic toys, household appliances etc..
| Name | Pin Header Connector |
| Pitch | 5.08mm |
| Type | Right angle type |
| Insulator Color | Black |
| Insulator | LCP+30%Glass Fiber, (UL94V-0) |
| Operation Temperature | -40℃ to +105℃ |
| Contact Resistance | 30mΩ Max |
| Current Rating | 7A |
| Contact Material | Brass |
| Insulation Resistance(min) | 1000M ohm Min |
| Contact Plated | Gold/Tin over Nickel |
| Processing Temperature | 260℃ for 10 seconds |
| Insulator material | PA6T PBT LCP |
| Packing | Bag packing |
| OEM/ODM | Accepted |
| Mounting Type | Through Holes |
